REDARC REDLAB Icon 100Ah Lithium Battery
Upgrade your 4WD or camping power system with 100Ah of usable capacity. Weighing 12kg, the REDARC REDLAB Icon combines compact dimensions with high-current performance and compatibility with REDARC BCDC chargers, Manager systems and inverters.
Features
- 100% usable capacity and 6,000+ charge cycles.
- IP67 dust and water protection with vibration-resistant construction.
- Internal heating for below-zero charging.
- Built-in display shows charge level and faults.
- Integrated isolation switch with fault-reset functionality.
- Independently verified to IEC 62619:2022.
Specifications
- Part number: LBATN12100
- Chemistry: Lithium
- Capacity: 100Ah
- Charge current: 100A
- Continuous discharge: 100A
- Recommended charging voltage: 14.2V
- Operating temperature: -20°C to 60°C
- Dimensions: 308 × 168 × 211mm (L × W × H)
- Weight: 12kg
- Warranty: 3 years
Inclusions
- 1 × REDARC REDLAB Icon 100Ah lithium battery.
Frequently Asked Questions
Can I connect multiple batteries?
Yes. Supports up to four in parallel or two in series for 24V applications.
Description
REDARC REDLAB Icon 100Ah Lithium Battery
Upgrade your 4WD or camping power system with 100Ah of usable capacity. Weighing 12kg, the REDARC REDLAB Icon combines compact dimensions with high-current performance and compatibility with REDARC BCDC chargers, Manager systems and inverters.
Features
- 100% usable capacity and 6,000+ charge cycles.
- IP67 dust and water protection with vibration-resistant construction.
- Internal heating for below-zero charging.
- Built-in display shows charge level and faults.
- Integrated isolation switch with fault-reset functionality.
- Independently verified to IEC 62619:2022.
Specifications
- Part number: LBATN12100
- Chemistry: Lithium
- Capacity: 100Ah
- Charge current: 100A
- Continuous discharge: 100A
- Recommended charging voltage: 14.2V
- Operating temperature: -20°C to 60°C
- Dimensions: 308 × 168 × 211mm (L × W × H)
- Weight: 12kg
- Warranty: 3 years
Inclusions
- 1 × REDARC REDLAB Icon 100Ah lithium battery.
Frequently Asked Questions
Can I connect multiple batteries?
Yes. Supports up to four in parallel or two in series for 24V applications.
