REDARC Trailer Mount Electric Trailer Brake Controller - EBTM

REDARC Trailer Mount Electric Trailer Brake Controller - EBTM. An electric trailer brake controller with the option of an encapsulated trailer mount unit. Ensures safe braking when towing. For protection against vibration and the weather, EBTM is completely potted in silicone elastomer. As the manual button is not needed, it has been removed and the EBTM requires an auxiliary 12 volt available at the trailer socket. You should ensure the 12 volt supply in the trailer is adequate to supply sufficient power for safe braking. Apart from this the unit operates as the standard EB does.

 Note: Confirm with local transport authorities regarding the usage for trailer mount electric trailer brake controllers in your state.

Features:

• Compact size.
• LED status and braking force indication.
• Override option for independent trailer brake activation.
• Simple gain adjustment for variation in braking force.
• 2 year warranty.

Specifications:

• Input voltage: 12V DC.
• Input fuse rating: 30A.
• Dimensions:
  • Height (mm): 30
  • Width (mm): 50
  • Depth/Length (mm): 100
  • Weight (g): 300
