REDARC TVMS Rogue Control Module - TVMS1240
REDARC TVMS Rogue Control Module - TVMS1240. A power control solution for caravan, camper and 4x4 applications, controlled via the physical screen or your Bluetooth connected mobile device, with in-built smart fuses. Provides real time and accurate state of charge, power input/output and ambient temperature information when combined with RedVision screen and Manager30 battery management system. Two analogue tank level inputs offer accurate monitoring of multiple tanks and the Rogue is compatible with most common tank level sensors. Allowing complete control for multiple on-board devices including lights, fans, fridges, and pumps. Its 10 output channels include dimming and the built-in switch inputs make the Rogue perfect for lighting circuits. The Rogue can connect up to 8 physical switches, control is not just limited to the RedVision screen or app. It enables lights to be controlled from each room of a caravan or for the addition of reed switches to trigger lights when opening a door. Easily provide automation of tedious tasks with just a press of a button to switch off everything except for your fridge or power down non-essential loads when your batteries are running low.
Note: Compatible with DISP4300-RC models manufactured from January 2023 (serial numbers beginning with "23"). Displays manufactured from July 2022 to January 2023 are upgradeable (serial numbers "2207" to "2212").
Features:
- 10x 10A dimmable outputs.
- 8x inputs allow for use with physical switches.
- Compact size.
- On-board smart fuses.
- Streamlined installation and configuration.
- Fully programmable.
- Accurate analogue tank level inputs.
- RedVision app is available for IOS and Android. A configurator app is only required for initial installation and set up.
- 2 year warranty.
Specifications:
- Operating Temperature -20°C to 70°C.
- Input Voltage: 9 - 16V.
- Max. Rated Output Current: 40A.
- Dimensions:
- Height (mm): 25
- Width (mm): 130
- Depth/Length (mm): 250
- Weight (kg): 0.43
