Outback Armour Rear Leaf Spring Trail Plus - OASU1178014

Outback Armour Rear Leaf Spring Trail Plus OASU1178014

Choose Outback Armour OASU1178014 rear leaf spring for the vehicle applications below. Chromium-alloy spring steel supports ride height and load carrying for the specified setup.

Specifications

• Part number: OASU1178014
• Product: Leaf Spring - LC78/79 Series - Trail Plus
• Supply unit: each
• Quantity required per vehicle: 2
• Lift rear: 50mm (@approx 250kg load)
• Configuration: 8 primary 2 secondary
• Features: Nylon slipper pads
• Steel: 60Si2Mn
• Paint / Finish: Black paint
• Recommended U-Bolt: OASU2384005

Fitment Notes

• Lift heights are approximate and conditional on vehicle variants and load distribution.

Inclusions

• 1 rear leaf spring

Vehicle Fitment

Toyota Land Cruiser: 78 Series (6 Cyl 1999-2006); 78 Series (V8 08/2012 - 08/2023); 78 Series (V8 2007-07/2012); 78 Series J7 (4 Cyl 2023+); 78 Series J7 (V8 2023+); 79 Series (Dual Cab) (V8 2012 - 08/2023); 79 Series (Dual Cab) J7 (4 Cyl 2023+); 79 Series (Dual Cab) J7 (V8 2023+); 79 Series (Single Cab) (6 Cyl Pre 2007); 79 Series (Single Cab) (V8 08/2012-09/2016); 79 Series (Single Cab) (V8 10/2016 - 08/2023); 79 Series (Single Cab) (V8 2007-07/2012); 79 Series (Single Cab) J7 (4 Cyl 2023+); 79 Series (Single Cab) J7 (V8 2023+)

FAQ

How do I choose the right spring? Match the vehicle, lift and regular accessory or cargo load. Stated lift heights are approximate.
