Enerdrive 2000W 24V True Sine Wave Inverter with AC Transfer & Safety Switch
Enerdrive 2000W 24V True Sine Wave Inverter with AC Transfer & Safety Switch. A true sine wave inverter to deliver power to sensitive equipment (e.g. power tools, computers, microwave ovens, televisions and other appliances that use up to 2000W of power for operation). A true sine wave inverter minimises the risk of damaging sensitive equipment you need on the road. Incorporates a 16A AC transfer switch to keep your appliances running with almost no break time on AC transfer, for seamless AC power transfer between mains/generator and inverter. Allowing simple installation on-board. A RCD safety switch unit is included that can monitor the flow of electricity through the inverter and detects any problems that may pose a risk to a personal safety. Enjoy moments that matter with a peace of mind, with Enerdrive | Dometic to keep you connected and powered, no matter where your journey takes you.
Features:
- Seamless 16A AC internal transfer switch.
- AC RCD/Safety switch with test button.
- Removable LED remote control display panel.
- Regulated pure sine wave output.
- Silent operation.
- Compact size for easy installation.
- USB Port for charging USB devices.
Specifications:
- AC Output Power: 2000W.
- AC Output Current: 8.7A.
- AC Output Voltage: 230 Vac / 50 Hz.
- AC Output Waveform: Sinewave (<3% THD).
- Nominal DC Input Voltage: 24.5 VDC.
- No Load battery draw: <1.5 ADC.
- DC Input Voltage operating range: 21.0 – 31.0 VDC.
- Under Voltage Alarm: 22.0/24.2 VDC.
- Under Voltage Alarm Recovery: 22.6 / 24.6 VDC.
- Under Voltage Shutdown: 21.0 / 23.6 VDC.
- Under Voltage Shutdown Recovery: 24.0 / 25.2 VDC.
- Over Voltage Shutdown: 31.0 VDC.
- USB Port: 5V, 2.1A.
- AC Transfer Switch:
- Transfer Time: <30ms.
- Transfer Relay Rating: 16A (resistive load).
- AC Input socket IEC-C20: 16A max.
- AC Output socket IEC-C19: 16A max.
- AC Output Front GPO: 10A max.
- Safety and Environmental:
- Conformance: All required Australian Standards, CE LVD: EN/IEC 62040-1, IEC61558-2-16.
- EMI / EMC: CE EMC: EN/IEC 62040-2 category C1.
- Agency Markings: RCM , CE.
- Operating Temperature: 0°C to 40°C.
- Storage Temperature: -20°C to 60°C.
- Relative Humidity: 5-90% non-condensing.
- Operating Altitude: Up to 3000 meters above sea level.
- 5 year warranty.
- Note: Specifications subject to change without notice. Power Drain from DC Battery Bank: Please note that there is a power drain of approx 700mA from the battery bank when the Inverter is running in AC By-Pass mode. In order to avoid draining down the battery bank, a battery charger with sufficient power is required to maintain the battery bank voltage.
Dimensions:
- Dimensions (mm): 444 (W)x 230 (L)x 115 (H).
- Weight (kg): 5.9.
