REDARC BCDC Core In-Cabin 40A DC Battery Charger - BCDCN1240

REDARC BCDC Core In-Cabin 40A DC Battery Charger - BCDCN1240. BCDC Core 40A DC to DC in-cabin battery charger, for in-cabin, canopy, or battery box setups where dust and weatherproofing isn’t required. Small compact size and no fan to be silent, can allow more space in the interior of the cabin. Features dual input DC charging tech plus an MPPT solar regulator and Green Power Priority all in the familiar and compact BCDC form factor. To efficiently charge from both the alternator and solar simultaneously to ensure maximum charge. Minimising the load on your alternator to save fuel in return. For lead acid battery banks over 200Ah and lithium batteries over 100Ah (large capacity battery banks may require a few cycles to fully charge). Check the manufacturer’s data for your battery and ensure that the ‘Continuous Current Rating’ of the charger does not exceed the manufacturer’s recommended maximum charging current.

Features:

Suitable for in-cabin and canopy installations only.
Compact form factor.
Designed, made and tested in Australia.
Simultaneous DC and solar charging with Green Power Priority.
Maximises the performance and life of your auxiliary battery.
Suits 12V/24V standard and variable voltage/smart alternators.
Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries.
Suitable for use on vehicles with conventional alternator charging systems.
2 year warranty.

Specifications:

Battery Chemistry: Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only.
Continuous Rating: 40A.
Power Type - AC DC: DC TO DC.
No Load Current: <100mA.
Solar Input Voltage: 9 - 32V.
Solar Switch On Voltage: 9V.
Standby Current: <8mA.
Operating Temperature: -15°C to 80°C.
Connector Type: Bare wire.
Input Voltage: 9 - 32V.
Output Voltage: 12V DC.
Max. Charging Voltage : 15.3V.
Max. Rated Output Current: 40A.
Nominal Output Power: 600W.
Input Fuse Rating: 60A (Not supplied) REDARC FK60 recommended.
Output Fuse Rating: 60A (Not supplied) REDARC FK60 recommended.

Dimensions:

Weight (g): 900
Height (mm): 37
Width (mm): 120
Depth/Length (mm): 165
